Tuesday, August 25, 2009

Comparison of Team Concert and Team Foundation Server Features

IBM Rational is playing catch up in the ALM tool space, Gartner reports notwithstanding.  Rational Team Concert 2.0 is an incremental step to answer MS Team Foundation Server 2008 and other ALM solutions.  Both tools are too large to compare in depth in one article.  The following article is a HIGH LEVEL comparison.

ALM disciplines and tools (modified from an earlier article)

ALM Discipline

TFS 2008

IBM Rational Team Concert

Requirements management

checkmark


checkmark

Design





Project Management

checkmark

checkmark

Change management

checkmark

checkmark

Configuration Management

checkmark

checkmark

Build management

checkmark

checkmark

Testing

checkmark

The future release will integrate with Quality Manager to extend work item traceability to testing artifacts

Release Management

checkmark

checkmark

Software Deployment

Software Maintenance/Asset Management



Table adopted from RTC edition comparison (https://jazz.net/downloads/rational-team-concert/releases/2.0)

Features

Express-C

Express

Standard

Enterprise

Microsoft Team Foundation Server

Server license

checkmark

checkmark

checkmark

checkmark

checkmark

Maximum Developers / Contributors

10 / unrestricted

50 / unrestricted

250 / unrestricted

unrestricted / unrestricted

practical limit of ~ 3600 TFS users

Database included (optional)

Derby only

Derby and DB2 Workgroup
(DB2, Oracle, SQL Server)

Derby and DB2 Workgroup
(DB2, Oracle, SQL Server)

Derby and DB2 Workgroup
(DB2, Oracle, SQL Server)

MS SQL Server

Application server included (optional)

Tomcat only

Tomcat (WebSphere)

Tomcat (WebSphere)

Tomcat (WebSphere)

IIS, WSS, MOSS

IDE support

Eclipse, Microsoft Visual Studio

Eclipse, Microsoft Visual Studio

Eclipse, Microsoft Visual Studio

Eclipse, Microsoft Visual Studio

Eclipse, Microsoft Visual Studio

Agile planning: daily, iteration, release

checkmark

checkmark

checkmark

checkmark

checkmark

Source code management

checkmark

checkmark

checkmark

checkmark

checkmark

Build management

checkmark

checkmark

checkmark

checkmark

checkmark

Work item tracking

checkmark

checkmark

checkmark

checkmark

checkmark

Customizable process

checkmark

checkmark

checkmark

checkmark

checkmark

Project milestone tracking and status

checkmark

checkmark

checkmark

checkmark

checkmark

Subversion integration

checkmark

checkmark

checkmark

checkmark

N/A

Role-based process permissions

checkmark

checkmark

checkmark

checkmark

checkmark

Project level access control

checkmark

checkmark

checkmark

checkmark

checkmark

LDAP authentication

checkmark

checkmark

checkmark

checkmark

N/A

Dashboards

(One per Project)

(One per Project)

(Unlimited Project, Team, and Personal)

(Unlimited Project, Team, and Personal)

Cross-project dashboards

checkmark

checkmark

checkmark

checkmark

Cross-repository dashboards

checkmark

checkmark

checkmark

checkmark

Customizable work item attributes and presentations

checkmark

checkmark

checkmark

Customizable work item workflow

checkmark

checkmark

checkmark

Plan risk assessment

checkmark

checkmark

Reports

checkmark

checkmark

checkmark

ClearCase Synchronizer and Bridge

checkmark

checkmark

N/A

ClearQuest Synchronizer and Bridge

checkmark

checkmark

N/A

LDAP import/synchronize

checkmark

checkmark

N/A

HTTP proxy support

checkmark

checkmark

checkmark

Floating licenses available

checkmark

checkmark

N/A

High availability

*checkmark

* Entitles installation of a second copy of the server in an idle standby application server failover configuration. Requires WebSphere Application Server and optional high availability database configuration (DB2, Oracle, SQL Server).

One note on dashboards.  TFS 2008 uses SharePoint portal, which allows all kinds of customizations, but there is no nice dashboard out of the box.  However, TFS 2010 will change all that.  See http://blogs.msdn.com/bharry/archive/2009/05/19/tfs-2010-project-management.aspx for more details.



Table adopted from RTC features (http://www-01.ibm.com/software/awdtools/rtc/standard/features/?S_CMP=rnav)

Features

RTC Benefits

TFS Benefits

(added for comparison by me)

Integrated work item management

Automatically creates and tracks progress of individual work items in accordance with team process and project rules. Additionally captures and maintains work item relationships to other artifacts, such as code change sets and builds.

TFS has had all features listed under RTC work item management. In addition, TFS extends its traceability and work item tracking to its integrated testing capability and testing artifacts. Automated tests can be incorporated into builds.

Integrated source control

Provides essential software version control, workspace management, and parallel development support to individuals and teams. Additionally, Rational Team Concert is fully aware and integrated into work items (why a code change was made) and build management (when did this code change make it to a build).

TFS has provided the same type of source control and work item management capabilities. Work item traceability also extends to test artifacts.

Integrated build management

Allows you to schedule and execute software build processes. Leverages multiple servers for rapid, cross-platform build processing. Integrates with work items and source control to create detailed bill of materials to guarantee build reproducibility.

TFS has had the same type of build management and execution capabilities.

Process awareness and automation

Guides team workflow with a customized project process and automates process steps and checkpoints at varying degrees of rigor.

Besides the out of the box MSF templates, TFS has process template manager to customize project and process templates. There are a number of templates, including open source Scrum, that may be readily imported and used.

Customizable project dashboard

Lets you stay on top of project progress, troubleshoot project problems, and take corrective action earlier in the project lifecycle.

TFS 2008 uses SharePoint portal, which allows all kinds of customizations, but there is no nice dashboard out of the box. However, TFS 2010 will change all that. See http://blogs.msdn.com/bharry/archive/2009/05/19/tfs-2010-project-management.aspx for more details.

ClearQuest Connector

Integrates the enterprise scalability of Rational® ClearQuest® for change and defect management while maintaining the integration with SCM and build management.

N/A

ClearCase Connector

Integrates the enterprise scalability of Rational ClearCase® for SCM while maintaining the integration with work item management and build management.

N/A

Subversion bridge

Integrates your investment in SCM while maintaining the integration with work item management and build management.

N/A

Team awareness and collaboration

Provides project-integrated presence and messaging.

TFS 2008 uses SharePoint/MOSS portals for project collaboration along with various alerts

Ready to use reports

Leverages ready to use reports to perform trend analysis and to make informed predictions based on patterns.

TFS 2008 has its own data warehouse with sophisticated reporting and analysis capabilities.



TFS vs RTC (modified from an earlier article)

Microsoft Visual Studio® 2008 Team Foundation Server

IBM Rational Team Concert v2.0

Platform and Languages



By default, only Microsoft Windows®



TeamPrise third-party partner solution enables cross-platform (i.e. Eclipse) clients.





Windows and Linux



Extensibility



.NET object model.

TFS Server web services based API





REST web services API



Traceability

Supports Work Item traceability out of the box

Supports Work Item traceability out of the box

Parallel Development



Supported through branches/merging and workspaces.





Supported through baselining and delivering change set from streams and workspaces and their respective flow targets

User Interaction (UI)



By default, only Windows and Microsoft Office solutions.

Team System Web Access by default; in addition, a separate Work Item Web Access (WIWA) client is available (free).

TFS Eclipse plug-in by TeamPrise





Eclipse IDE plug-ins;  Visual Studio IDE plug-in;

Web clients by default



Distributed Development



No offline support.





No offline support.



Developer Workspaces



Private workspaces on local disk that must be updated manually.



Jazz Source Control enables private workspaces that can be updated manually.

Scalability Limits



500 Team Projects is the maximum that one TFS server can support.

Up to 3600 TFS users





Not enough information about limits





Team Concert Prices (IBM RTC pricing is based on version 1.0)

Part description

*IBM price excluding tax

IBM Rational Team Concert Contributor Client Access Authorized User License + SW Subscription & Support 12 Months (D041ILL)

630.00

IBM Rational Team Concert Express Edition Developer Client Access Authorized User License + SW Subscription & Support 12 Months (D041FLL)

1,260.00

Part description

*IBM price excluding tax

IBM Rational Team Concert Contributor Client Access Authorized User License + SW Subscription & Support 12 Months (D041ILL)

630.00

IBM Rational Team Concert Express Edition Developer Client Access Authorized User License + SW Subscription & Support 12 Months (D041FLL)

1,260.00

IBM Rational Team Concert Express Edition Server Install with 3 Authorized Users License + SW Subscription & Support 12 Months (D041CLL)

6,300.00

Part description

*IBM price excluding tax

IBM Rational Team Concert Contributor Client Access Authorized User License + SW Subscription & Support 12 Months (D041ILL)

630.00

IBM Rational Team Concert Standard Edition Developer Client Access Authorized User License + SW Subscription & Support 12 Months (D041ULL)

4,100.00

IBM Rational Team Concert Standard Edition Server Install with 3 Authorized Users License + SW Subscription & Support 12 Months (D041TLL)

52,500.00

IBM Rational Team Concert Standard Edition Floating Developer Client Access Floating User License + SW Subscription & Support 12 Months (D06F4LL)

7,180.00

IBM Rational Team Concert Standard Edition Floating Contributor Client Access Floating User License + SW Subscription & Support 12 Months (D06F9LL)

1,760.00

Team Foundation Server Prices

Visual Studio Team System 2008 Team Foundation Server

$2,799

Visual Studio Team System 2008 Team Foundation Server Client Access License (CAL)

$499



References

IBM ALM products roadmap

http://www-01.ibm.com/software/rational/jazz/roadmap/

IBM Rational Team Concert Editions Comparison

https://jazz.net/downloads/rational-team-concert/releases/2.0

VSTS & TFS 2008

VSTS Product comparison

http://msdn.microsoft.com/en-us/vsts2008/products/cc149003.aspx

TFS 2008

http://msdn.microsoft.com/en-us/tfs2008/default.aspx

TFS 2010 dashboards

http://blogs.msdn.com/bharry/archive/2009/05/19/tfs-2010-project-management.aspx
